Specifications
| Brand | HIKVISION |
| Range | SOLUTIONS |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 18 Additional IP CH: Up to 34 IP channels (12 Mpx), replacing all BNC channels |
| Bandwidth | 320 Mbps |
| Video outputs | HDMI 1: 1080p HDMI 2: 4K VGA BNC CVBS |
| Display resolution | HDMI 1: 1920×1080, 1280×1024, 1280×720, 1024×768 / 60Hz HDMI 2: 4K (3840×2160), 2K (2560×1440), 1920×1080, 1280×1024, 1280×720, 1024×768 / 60Hz VGA: 1920×1080, 1280×1024, 1280×720, 1024×768 / 60Hz CVBS: 704×576 (PAL) / 704×480 (NTSC) |
| Audio inputs | 16 RCA channels |
| Audio outputs | 2 RCA channels |
| Bidirectional audio | 1 channel RCA |
| Audio Bit Rate | 64 Kbps |
| Audio compression | G.711u |
| Video compression | Analog: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 IP: H.265+ / H.265 / H.264+ / H.264 |
| Input resolution | HDTVI: 8 MPx, 3K, 5 MPx, 4 MPx, 3 MPx, 1080, 720p HDCVI: 4MP, 1080p, 720p AHD: 5MPx, 4 MPx, 1080p, 720p CVBS: PAL/NTSC |
| Main Stream coding | 8Mpx@8 FPS; 3K@12 FPS, 5Mpx@12 FPS; 4Mpx @15 FPS; 3Mpx@18 FPS; 1080p/720p/WD1/4CIF/VGA/CIF@25 FPS(P) |
| Extra Stream coding | WD1 / 4CIF / CIF (25 FPS) |
| Video Bit Rate | 32 Kbps at 10 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | 16 inputs / 8 relay |
| Motion Detection | Motion detection 2.0: Deep-learning based motion detection, can classify humans and vehicles upon motion detection. Enabled by default on all analog channels. |
| Artificial intelligence | Acusense: Perimeter protection based on VCA rules with false alarm filter for human and vehicle detection applied on: Line Crossing, Area Intrusion. Available in up to 8 analog video channels. |
| POS | Yes |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 8 HDD SATA 3.5″ of up to 12 TB each (not included) |
| RAID | RAID 0, 1, 5, 6 and 10 |
| Communication | 2 x USB 2.0 (front panel) / 1 x USB 3.0 (back panel) / 2 x RJ45 10M/100M/1000M / 1 x RS-485 full-duplex / 1 x RS-232 |
| Remote connections | 128 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | AC 100~240 V, ≤ 35 W (without HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions / Weight | 445 (W) x 465 (D) x 88 (H) mm / ≤ 9 Kg (w/o HDD) |
Description
- Hikvision
- SOLUTIONS range
- DVR 5n1
- 16 CH video HDTVI/HDCVI/AHD/CVBS / 34 IP
- H.265 Pro+/H.265/H.264+/H.264
- Maximum input resolution 4K @8fps
- Audio
- Motion detection 2.0 on all channels
- AcuSense, false alarm filter for vehicles and persons in up to 8 channels
- HDMI output 4K, HDMI 1080p, VGA and CVBS
- Loop video output
- PTZ Control (RS485/Coaxial)
- Space for 8 hard disk drives
