Specifications
| Brand | Hikvision |
| Range | HiWatch Series |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 4 Channels BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 4 BNC channels and 1 IP channels (up to 1080p) |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 RCA channel | 4 Channels via coaxial cable |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Video / audio compression | H.264+ / H.264 |
| Display resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Total bandwidth | 32 Kbps at 4 Mbps |
| Recording resolution | 1080p Lite / 720p / WD1 / 4CIF /VGA / CIF |
| Main Stream coding | When 1080p Lite mode is activated: 1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF (1~25 FPS) When 1080p Lite mode is not activated: 720p / WD1 / 4CIF / VGA / CIF (1~25 FPS) |
| Extra Stream coding | 2CIF (1~6 FPS), CIF / QVGA / QCIF (1~25 FPS) |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 1 HDD SATA 3.5″ of up to 6TB (not included) |
| Communication | 2 x USB 2.0 (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote access | Web Browser, Smartphone App IVMS 4500 and PC Software IVMS 4200 |
| Power | DC 12 V / 1500 mA |
| Dimensions / Weight | 45 (H) x 260 (W) x 222 (D) mm / 0.8 Kg |
Description
- Hikvision HiWatch Series
- DVR 5n1
- 4 CH video HDTVI/HDCVI/AHD/CVBS / 1 IP / 1 CH audio
- H.264+/H.264
- Resolution per channel: 1080PLite/720P (25FPS)
- Audio over coaxial cable
- PTZ Control (Coaxial)
- Full HD HDMI and VGA Output
- Mouse
- Space for 1 HDD
